Zeiss Supreme Prime Radiance 40mm T1.5 Cinema Lens with PL-Mount
Overview
The Zeiss Supreme Prime Radiance 40mm T1.5 Cinema Lens with PL-Mount is a standard spherical prime that covers Vista Vision sensors. A standard focal length sees close to natural human perspective, which suits dialogue and coverage where the framing should not draw attention to itself. A T1.5 maximum aperture puts this among the fastest cine glass available, giving very shallow depth of field and workable exposure in low light, and the lens closes to T22. It uses a PL-Mount with manual focus. Zeiss eXtended Data passes lens metadata through the mount, including distortion and shading characteristics for post.
Features
Key Features
Standard Vista Vision Coverage
The lens covers Vista Vision sensors, projecting a 46.3 mm image circle. A standard field of view sits near natural perspective, the neutral option for dialogue and everyday coverage where framing should not announce itself.
T1.5 Maximum Aperture
T1.5 puts this among the fastest cine glass available. Depth of field wide open is measured in inches at close range, which demands an experienced focus puller and rewards one with separation no slower lens produces. It closes to T22.
300° Focus Throw
Its 300° focus throw is long, spreading distance marks widely for precise, repeatable pulls, with a slower full rack as the trade.
User-Interchangeable Mount
The mount can be swapped by the owner, letting one lens follow a camera package across bodies rather than staying tied to whichever mount it shipped with. That matters most to owner-operators buying into a system they expect to change.
Zeiss eXtended Data
Alongside focus and aperture, the lens reports its own distortion and shading characteristics. Post can remove and reapply those precisely, which matters when compositing into a frame the lens has bent.
Focus & Handling
1.3 ft Minimum Focus
Mount & Rig Integration
PL-Mount
The lens mounts via PL-Mount, fitting industry-standard cinema cameras and adapting to most modern cinema and hybrid bodies.
0.8-Pitch Cine Gears
The lens carries 0.8-pitch cine gears, the standard pitch for follow focus units and lens motors. Compatibility with lens control systems lets a solo operator make consistent, repeatable focus pulls, or a camera assistant control the lens remotely.
95mm Front Diameter
The front element measures 95mm, which fits a compact matte box directly and steps up to a 114 mm clamp with an adapter ring. Matte box fit follows from this measurement rather than from the filter thread, since the clamp grips the outside of the barrel.
